76KG Ozone Generator
Highly efficient and energy-saving, ozone utilization rate is as high as 95%
The application of IGBT inverter medium-frequency high-voltage power supply can effectively improve ozone generation efficiency, achieve high efficiency and energy saving, and ensure continuous and stable operation.
The power supply part adopts a modular design, and the equipment discharge unit has high efficiency and easy maintenance.
The ozone system uses water cooling technology to maintain efficient and stable ozone production.
The discharge tube adopts advanced high borosilicate tube discharge technology.
In modern industry, flue gas denitrification has become a vital environmental protection task. With the increasingly stringent environmental regulations, traditional flue gas denitrification processes can no longer meet the current emission reduction needs. Therefore, the flue gas denitrification technology of ozone generators has gradually been recognized and promoted. Among them, 75kg ozone generators, as a high-efficiency denitrification equipment, have been widely used in many fields.
1. The principle of flue gas denitrification of ozone generators
Ozone is a gas with strong oxidizing ability, with a molecular formula of O₃ and a molecular weight of 48g/mol. At normal temperature and pressure, ozone can be decomposed into oxygen, single oxygen atoms (O), hydroxyl groups (OH) and free hydroxyl groups (-O-), all of which have strong chemical activity. In the process of flue gas denitrification, the ozone generator converts the input oxygen into ozone, which is then injected into the flue gas containing NOx. The strong oxidizing property of ozone can oxidize NO (nitric oxide) in flue gas into high-valent nitrogen oxides such as NO₂, N₂O₃, and N₂O₅. These high-valent nitrogen oxides are more soluble in water and absorbed by alkaline solutions in the subsequent spray scrubber, and finally converted into harmless nitrogen.
The specific chemical reaction process includes:
2NO + 3O₃ = N₂O₅ + 3O₂
2NO₂ + O₃ = N₂O₅ + O₂
Through these reactions, NOx in flue gas is effectively removed, achieving the purpose of flue gas denitrification.
2. Application advantages of 75kg ozone generator
1. High denitrification efficiency
The 75kg ozone generator has a high denitrification efficiency, and its NOx removal rate can reach more than 95%. This is mainly due to the strong oxidizing property of ozone and its rapid reaction speed with NOx. Even at low concentrations, ozone can instantly react with NOx for oxidation, thereby saving reaction space and improving denitrification efficiency.
2. Low operating cost and easy maintenance
In addition to its efficient denitrification capacity and environmental advantages, the 75kg ozone generator also shows significant advantages in operating costs and maintenance. The ozone generator adopts advanced oxygen conversion technology, which can effectively improve the efficiency of ozone generation and reduce energy consumption. At the same time, the equipment structure is reasonably designed, and the key components are made of corrosion-resistant and wear-resistant materials, which ensures long-term stable operation and reduces the failure rate and maintenance frequency. In addition, the equipment has a high degree of automation and is equipped with an intelligent control system, which can realize remote monitoring and automatic adjustment, reducing the cost of manual operation. On the whole, the 75kg ozone generator not only ensures efficient denitrification, but also takes into account economy and ease of use. It is an ideal choice for modern industrial flue gas denitrification and is of great significance to promoting green and sustainable development.
